Omron Inverter 3G3RX2-B413K,V/f, Sensorless Vector, Close Loop Vector
Part number:3G3RX2-B413K
Availability: In stock
Contact us: inquiry@lanenelectric.com
Send Inquiry
Product Details of Omron Inverter 3G3RX2-B413K,V/f, Sensorless Vector, Close Loop Vector
Product Introduction
Specification
| Built-in Communications | Modbus built-In |
| Control Type | V/f, Sensorless Vector, Close Loop Vector |
| Flow-chart logic programming | Yes |
| Mounting | Vertical Mount |
| Power Phase | 3-phase |
| Speed range | 0.01 - 400 Hz |
| Starting torque | 2 |
| Supply Voltage | 480 VAC |
| Power Phase | 3-phase |
| Constant Torque-Horsepower | 177 HP |
| Constant Torque-Current | 260 A |
How to Select Required Support Software for Your Controller
The required Support Software depends on the Controller to connect. Please check the following table when purchasing the Support Software.
*1. Multi licenses are available for the CX-One (3, 10, 30, or 50 licenses).
Note: 1. For details, refer to the CX-One Catalog (Cat. No. R134), visit your local OMRON website.
2. The RX2-series is supported by CX-Drive version 3.00 or higher.
For details, refer to your local OMRON website and Sysmac Studio Catalog (Cat. No. P138).
Note: The RX-series with EtherCAT Communication Unit 3G3AX-RX2-ECT version 1.0 or later is supported by Sysmac Studio version 1.47 or higher.
| Item | Omron PLC System | Omron Machine Automation Controller System |
|---|---|---|
| Controller | CS, CJ, CP, and other series | NJ series |
| Inverter | Inverter RX2-series | Inverter RX2-series with EtherCAT Communication Unit 3G3AX-RX2-ECT |
| Software | FA Integrated Tool Package CX-One (CX-Drive: Version 3.00 or higher) |
Automation Software Sysmac Studio (Version 1.47 or higher) |
Note: Select options by the maximum applicable motor capacity of heavy and light load rating.
related options
| Output | Rated output current (A) |
VLD | 33.0 | 46.0 | 60.0 | 80.0 | 93.0 | |
|---|---|---|---|---|---|---|---|---|
| LD | 30.0 | 40.0 | 56.0 | 73.0 | 85.0 | |||
| ND | 25.0 | 32.0 | 46.0 | 64.0 | 76.0 | |||
| Overload current rating |
VLD | 110% 60 sec / 120% 3 sec | ||||||
| LD | 120% 60 sec / 150% 3 sec | |||||||
| ND | 150% 60 sec / 200% 3 sec | |||||||
| Rated output voltage | 3-phase (3-wire) 200 to 240 V (depending on receiving voltage) | |||||||
| Rated capacity (kVA) |
200 V | VLD | 11.4 | 15.9 | 20.8 | 27.7 | 32.2 | |
| LD | 10.4 | 13.9 | 19.4 | 25.3 | 29.4 | |||
| ND | 8.7 | 11.1 | 15.9 | 22.2 | 26.3 | |||
| 240 V | VLD | 13.7 | 19.1 | 24.9 | 33.3 | 38.7 | ||
| LD | 12.5 | 16.6 | 23.3 | 30.3 | 35.3 | |||
| ND | 10.4 | 13.3 | 19.1 | 26.6 | 31.6 | |||
| Motor start torque *4 | 200%/0.3 Hz | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| Braking | Regenerative braking | Equipped with braking resistance circuit (with a discharging resistor separately installed) |
|||||||
| Minimum resistance that can be connected (Ω) |
100 | 100 | 100 | 70 | 70 | 35 | |||
| Dimen- sion |
Height (mm) | 255 | 255 | 255 | 255 | 260 | 260 | ||
| Width (mm) | 150 | 150 | 150 | 150 | 210 | 210 | |||
| Depth (mm) | 140 | 140 | 140 | 140 | 170 | 170 | |||
| Protective construction | IP20 *5 / UL open type | ||||||||
| Approximate mass (kg) | 3 | 3 | 3 | 3 | 6 | 6 | |||
software
Note: For details, refer to the CX-One Catalog (Cat. No. R134), visit your local OMRON website.
Automation Software Sysmac Studio
built-in EMC filter
The RX2 Inverter can perform simple sequence control programmed using support software CX-Drive.
Crane control, tension control, and other large-scale processes that require fast control speeds can be configured without a PLC, optimizing costs.
Built-in EMC Filter
