Mitsubishi PLC A1SD70 Melsec Electric Positioning Unit Analog Output Type
Part number: A1SD70
Availability: In stock
Contact us: inquiry@lanenelectric.com
Send Inquiry
Product Details of Mitsubishi PLC A1SD70 Melsec Electric Positioning Unit Analog Output Type
Product Introduction
l Part No: A1SD70
l Product name: Mitsubishi PLC A1SD70 Melsec Electric Positioning unit Analog output type
l Brand: Mitsubishi
l Place of Origin: Japan
l Warranty: 1 Year
l Number of control axes : 1 axis
l Positioning data : 1 data
l Positioning
l mode : Position control mode
l Speed → Position control switching mode
l Positioning method : Position control mode: Absolute method / Increment method can be selected for each axis
l Speed → Position control switching Control mode: Increment method
l Position command : -2147483648 ～ 2147483647 pulse
l Speed command : 1-400000 pulse / s
l Acceleration / deceleration processing : Automatic trapezoidal acceleration / deceleration
l Automatic acceleration / deceleration time : Acceleration: 2-9999ms
l Deceleration: 2-9999ms
l Imposition range : 1-2047 pulse
l Backlash correction : none
l Error correction function : none
l Speed command output : DC0 to ± 10V
l Positioning feedback pulse input : DC0 to ± 10V
l Pulse frequency : 100k pulse / s
l Connectable encoder type : Open collector, TTL, differential output
l Multiply setting : The number of feedback pulse inputs can be multiplied by 4, 2, 1, 1/2.
l Home return control : ・ With origin address change function
l ・ Origin return method and direction depend on switch settings
l JOG driving : none
l M function : none
l External power supply Voltage :DC + 15V / DC-15V
l Current : DC + 15V: 0.2A
l DC-15V: 0.02A
l Number of I / O occupied points :
l 48 points, 2 slots (I / O allocation: 16 empty points + 32 special points)
l DC5V internal current consumption: 0.30A
l External dimensions : 130mm* 69.5mm * 93.6mm
l mass : 0.40kg
