Specification

NX701-1600 Omron

Communication ports	EtherCAT and 2x Gigabit EtherNet/IP built in
Flash memory port	SD, USB Host
I/O capacity	64,000 with NX I/O
Maximum number of units	0
Min Cycle Time	0.125 ms
Motion Control Network	EtherCAT
Mounting	DIN Rail
Program capacity	80 MB
Programming Connection	USB / Ethernet
Programming language	Ladder / Structured Text / Function Block

Integration And functionality

Product name	Specifications		Model
Battery Set	Battery for NX701-[][][][]/ NJ501-[][][][]/ NJ301-[][][][]/ NJ101-[][][][] NJ/NX-Series CPU Unit maintenance	Note: 1. The battery is included as a standard accessory with the CPU Unit. 2. The battery service life is 2.5 years at 25°C. (The service life depends on the ambient operating temperature and the power conditions.) 3. Use batteries within two years of manufacture.	CJ1W-BAT01
End Cover	Mounted to the right-hand side of NX-Series CPU Racks.	One End Cover is provided as a standard accessory with each CPU Unit and I/O Interface Unit.	NX-EN

Item		Specification
Enclosure		Mounted in a panel
Grounding Method		Ground to less than 100 Ω
Dimensions (height × depth × width)		100 mm × 100 mm × 132 mm
Weight		880 g (including the End Cover)
Power consumption		40 W (including SD Memory Card and End Cover)
Operation Environment	Ambient Operating Temperature	0 to 55°C
	Ambient Operating Humidity	10% to 95% (with no condensation)
	Atmosphere	Must be free from corrosive gases.
	Ambient Storage Temperature	-25 to 70°C (excluding battery and fan unit)
	Altitude	2,000 m or less
	Pollution Degree	2 or less: Meets IEC 61010-2-201.
	Noise Immunity	2 kV on power supply line (Conforms to IEC 61000-4-4.)
	Overvoltage Category	Category II: Meets IEC 61010-2-201.
	EMC Immunity Level	Zone B
	Vibration Resistance	Conforms to IEC 60068-2-6. 5 to 8.4 Hz with 3.5-mm amplitude, 8.4 to 150 Hz Acceleration of 9.8 m/s² for 100 min in X, Y, and Z directions (10 sweeps of 10 min each = 100 min total)
	Shock Resistance	Conforms to IEC 60068-2-27. 147 m/s², 3 times in X, Y, and Z directions (100 m/s² for Relay Output Units)
Battery	Life	2.5 years (at 25°C, Power ON time rate 0% (power OFF))
Battery	Model	CJ1W-BAT01
*Applicable Standards 1**		cULus, EU, UKCA, RCM, KC, NK, LR

NX701-1600 Omron Automation and Safety
