Mitsubishi MR-JE-70B Servo Amplifier AC Servos MELSERVO Drive 700W 200V
Part number: MR-JE-70B
Availability: In stock
Contact us: inquiry@lanenelectric.com
Send Inquiry
Product Details of Mitsubishi MR-JE-70B Servo Amplifier AC Servos MELSERVO Drive 700W 200V
Product Introduction
● Part No: MR-JE-70B
● Product name: Mitsubishi MR-JE-70B Servo Amplifier AC Servos MELSERVO Drive 700W 200V
● Brand: Mitsubishi
● Place of Origin: Japan
● Warranty: 1 Year
● Condition: Original New with sealed box
● Minimum Order Quantity (MOQ): 1 piece
● Power(kw): 0.7kW
● Power Supply 1 Phase (VAC):200-240
● Power Supply 3 Phase (VAC):200-240
● RatedCurrent: 1.5A
● Dynamic Brake: Built-in
● SafetyFunction: STO(IEC/EN 61800-5-2)
● Weight:1.5kg
| Product Application |
Mitsubishi Servo Drive MELSERVO-JE Series MR-JE-70B is widely used in various production lines and machinery manufacturing and other fields.
● Factory Automation Systems: Programmable controllers, AC servo systems, inverters, industrial robots, processing machines
● Energy Systems: Power generation systems, transmission & distribution systems, medium- & low-voltage switchgear and systems, nuclear systems, power information & communication technology
● Glass industry, construction machinery, textile machinery, water treatment.
● Steel industry, combustion control systems, non-ferrous metal smelting.
MR-JE-A (General-purpose Interface) Specifications. Servo amplifier model MR-JE-. 10A. 20A. 40A. 70A. 100A. 200A. 300A. Output. Rated voltage. 3-phase 170 ...
Digital AC-Servo Amplifier MR-JE, for Rated Motor Power up to 2000 W
| Related Products |
Mitsubishi MR-JE-70B Servo Amplifier AC Servos MELSERVO Drive 700W 200V
MR-JE high performance servo amplifier - 700W SSCNET IIIH (200V)
| Technical specification | |
| Speed frequency response: | 2.0kHz |
| Performance: | 0.7kW (700W) |
| Control method: | Sinusoidal PWM control/current control system |
| Dynamic brake: | Built-in* |
| Position control mode: | |
| Max input pulse frequency: | 4 Mpps (differential receiver); 200kpps (open-collector) |
| Positioning feedback pulse: | Encoder resolution: 131072 pulses/rev |
| Torque limit: | Set by parameters or external analogue input |
| (0-10V d.c./max torque) | |
| Speed control mode: | |
| Control range: | Analogue speed command 1:2000, internal speed command 1:5000 |
| Speed fluctuation rate: | ±0.01% max (load fluctuation: 0-100%), 0% (power fluctuation: ±10%) |
| ±0.2% max (ambient temperature: 25°C (±10°C) only when using analogue speed command | |
| Torque limit: | Set by parameters or external analogue input |
| (0-10V d.c./max torque) | |
| Torque control mode: | |
| Analogue torque command input: | 0-±8V d.c./max torque |
| (input impedance: 10-12KΩ) | |
| Speed limit: | Set by parameters or external analogue input |
| (0-±10V d.c./rated speed) | |
| Power supply: | 200V |
| Power supply input 50/60Hz: | Single phase 200-240V a.c. |
| Three phase 200-230V a.c. | |
| SSCNET IIIH command communication cycle: | 0.444ms, 0.888ms |
| Protective functions: | Overcurrent shutdown, regeneration overvoltage shutdown, overload shutdown (electronic thermal), encoder fault protection, regeneration fault protection, undervoltage/sudden power outage protection, overspeed protection, excess error protection |
| Structure (IP): | Self-cooling, open (IP20) |
| Ambient temperature: | |
| Operation: | 0 to +55ºC |
| Storage: | -20 to +65ºC |
| Weight: | 1.5kg |
| Dimensions: | w70 x h156 x d185mm |
| *When using the built-in dynamic brake, refer to the instruction manual for the permissible load to motor inertia ratio. | |
| Hardware features: | |
| High accuracy positioning (encoder resolution 131072 pulse/rev) | |
| Compact amplifier and motor size | |
| Software features: | |
| Real-time autotuning | |
| Adaptive vibration suppression control function | |
| Includes protection against: | |
| Overcurrent, overload and regeneration overvoltage shutdown | |
| Servomotor overheating | |
| Encoder and regeneration faults | |
| Undervoltage/sudden power outage | |
| Overspeed and excess error | |
